Automata Network is an OP stack based Layer 2 Optimium acting as a modular attestation layer that extends machine-level trust to Ethereum with TEE Coprocessors and an EigenLayer AVS.


Value secured
$9.97 K21.8%
Canonically Bridged
$9.97 K
Externally Bridged
$0.00
Natively Minted
$0.00

  • Tokens
  • Daily UOPS
    0.000.00%
  • 30D ops count
    11.62 K

  • Type
    Optimium
  • Purpose
    Universal
  • Sequencer failureState validationData availabilityExit windowProposer failure

    Badges

    About

    Automata Network is an OP stack based Layer 2 Optimium acting as a modular attestation layer that extends machine-level trust to Ethereum with TEE Coprocessors and an EigenLayer AVS.

    Recategorisation

    144d
    21h
    17m
    10s

    The project will be classified as "Other" due to its specific risks that set it apart from the standard classifications.

    The project will move to Others because:

    The proof system isn't fully functional

    Consequence: projects without a proper proof system fully rely on single entities to safely update the state. A malicious proposer can finalize an invalid state, which can cause loss of funds.

    There is no data availability bridge

    Consequence: projects without a data availability bridge fully rely on single entities (the sequencer) to honestly rely available data roots on Ethereum. A malicious sequencer can collude with the proposer to finalize an unavailable state, which can cause loss of funds.

    Learn more about the recategorisation here.

    Value Secured
    Canonical
    External
    Native
    Activity
    Automata
    Ethereum
    Risk summary
    Risk analysis
    Sequencer failureState validationData availabilityExit windowProposer failure

    Sequencer failure

    Self sequence

    In the event of a sequencer failure, users can force transactions to be included in the project’s chain by sending them to L1. There can be up to a 12h delay on this operation.

    State validation

    None

    Currently the system permits invalid state roots. More details in project overview.

    Data availability

    External

    Proof construction and state derivation rely fully on data that is NOT published onchain. A custom data availability (DA) provider without attestations is used, but data unavailability can be challenged.

    Exit window

    None

    There is no window for users to exit in case of an unwanted regular upgrade since contracts are instantly upgradable.

    Proposer failure

    Cannot withdraw

    Only the whitelisted proposers can publish state roots on L1, so in the event of failure the withdrawals are frozen.

    Technology

    Fraud proofs are not enabled

    OP Stack projects can use the OP fault proof system, already being deployed on some. This project though is not using fault proofs yet and is relying on the honesty of the permissioned Proposer and Challengers to ensure state correctness. The smart contract system permits invalid state roots.

    • Funds can be stolen if an invalid state root is submitted to the system (CRITICAL).

    1. L2OutputOracle.sol - source code, deleteL2Outputs function

    Data required to compute fraud proof is published offchain without onchain attestations

    The project relies on DA challenges for data availability. If a DA challenger finds that the data behind a tx data commitment is not available, they can submit a challenge which requires locking a bond within 12h. A challenge can be resolved by publishing the preimage data within an additional 12h. In such a case, a portion of the challenger bond is burned, with the exact amount estimated as the cost incurred by the resolver to publish the full data, meaning that the resolver and challenger will approximately lose the same amount of funds. The system is not secure if the malicious sequencer is able to outspend the altruistic challengers. If instead, after a challenge, the preimage data is not published, the chain reorgs to the last fully derivable state. This mechanism fully depends on the derivation rule of the L2 node and can only be verified in its source code, which can be reviewed here.

    • Funds can be stolen if the sequencer is malicious and is able to economically outspend the altruistic challengers.

    • Funds can be stolen if there is no challenger willing to challenge unavailable data commitments.

    1. OP Plasma specification
    2. Universal Plasma and DA Challenges - Ethresear.ch
    3. Derivation: Batch submission - OP Mainnet specs
    4. BatchInbox - address
    5. OptimismPortal.sol - source code, depositTransaction function
    Data availability

    Automata DA is a data availability solution using data availability challenges (DA Challenges).

    Risk analysis
    Economic security
    DA Challenges

    There are no onchain assets at risk of being slashed in case of a data withholding attack. However, there is a mechanism that allows users to challenge unavailability of data. The system is not secure if the malicious sequencer is able to outspend the altruistic challengers, and there is no pool of funds onchain to incentivize challengers.

    Fraud detection
    None

    There is no fraud detection mechanism in place. A data withholding attack can only be detected by nodes downloading the full data from the DA layer.

    Committee security
    None

    The committee does not meet basic security standards, either due to insufficient size, lack of member diversity, or poorly defined threshold parameters. The system lacks an effective DA bridge and it is reliant on the assumption of an honest sequencer, creating significant risks to data integrity and availability.

    Upgradeability
    No delay

    There is no delay in the upgradeability of the bridge. Users have no time to exit the system before the bridge implementation update is completed.

    Relayer failure
    No mechanism

    The relayer role is permissioned, and the DA bridge does not have a Security Council or a governance mechanism to propose new relayers. In case of relayer failure, the DA bridge will halt and be unable to recover without the intervention of a centralized entity.

    Technology

    Architecture

    gmnetworkDA layer ## Data Availability Challenges Automata relies on DA challenges for data availability. The DA Provider submits an input commitment on Ethereum, and users can request the data behind the commitment off-chain from the DA Provider. If a DA challenger finds that the data behind a tx data commitment is not available, they can submit a challenge which requires locking a bond within 12h. A challenge can be resolved by publishing the preimage data within an additional 12h. In such case, a portion of the challenger bond is burned, with the exact amount estimated as the cost incurred by the resolver to publish the full data, meaning that the resolver and challenger will approximately lose the same amount of funds. The system is not secure if the malicious sequencer is able to outspend the altruistic challengers. If instead, after a challenge, the preimage data is not published, the chain reorgs to the last fully derivable state. Only hashes of data batches are posted as DA commitments to an EOA on Ethereum. However, there is a mechanism that allows users to challenge unavailability of data.

    • Funds can be lost if the sequencer posts an invalid data availability certificate and there are no challengers.

    • Funds can be lost if the sequencer posts an invalid data availability certificate, and he is able to outspend the challengers.

    1. Alt-DA Specification
    2. Security Considerations - Ethresear.ch
    Operator

    The system has a centralized operator

    The operator is the only entity that can propose blocks. A live and trustworthy operator is vital to the health of the system.

    • MEV can be extracted if the operator exploits their centralized position and frontruns user transactions.

    1. L2OutputOracle.sol - source code, CHALLENGER address
    2. L2OutputOracle.sol - source code, PROPOSER address

    Users can force any transaction

    Because the state of the system is based on transactions submitted on the underlying host chain and anyone can submit their transactions there it allows the users to circumvent censorship by interacting with the smart contract on the host chain directly.

    1. Sequencing Window - OP Mainnet Specs
    2. OptimismPortal.sol - source code, depositTransaction function
    Withdrawals

    Regular exit

    The user initiates the withdrawal by submitting a regular transaction on this chain. When the block containing that transaction is finalized the funds become available for withdrawal on L1. The process of block finalization takes a challenge period of 7d to complete. Finally the user submits an L1 transaction to claim the funds. This transaction requires a merkle proof.

    • Funds can be frozen if the centralized validator goes down. Users cannot produce blocks themselves and exiting the system requires new block production (CRITICAL).

    1. OptimismPortal.sol - source code, proveWithdrawalTransaction function
    2. OptimismPortal.sol - source code, finalizeWithdrawalTransaction function
    3. L2OutputOracle.sol - source code, PROPOSER check

    Forced exit

    If the user experiences censorship from the operator with regular exit they can submit their withdrawal requests directly on L1. The system is then obliged to service this request or halt all withdrawals, including forced withdrawals from L1 and regular withdrawals initiated on L2. Once the force operation is submitted and if the request is serviced, the operation follows the flow of a regular exit.

    1. Forced withdrawal from an OP Stack blockchain
    Other considerations

    EVM compatible smart contracts are supported

    OP stack chains are pursuing the EVM Equivalence model. No changes to smart contracts are required regardless of the language they are written in, i.e. anything deployed on L1 can be deployed on L2.

    1. Introducing EVM Equivalence
    Permissions

    The system uses the following set of permissioned addresses:

    Challenger EOA 1

    Challenger is an actor allowed to challenge or delete state roots proposed by a Proposer.

    Guardian EOA 5

    Guardian is an actor allowed to pause deposits and withdrawals.

    Proposer EOA 4

    Proposer is an actor allowed to post new state roots of the current layer to the host chain.

    Sequencer EOA 3

    Sequencer is an actor allowed to commit transactions from the current layer to the host chain.

    AutomataMultisig 0x03eC…39c8
    • A Gnosis Safe with 3 / 4 threshold.
    • Can act on behalf of ProxyAdmin.
    • Can change the configuration of AddressManager - set and change address mappings - acting via ProxyAdmin.
    • Can upgrade the implementation of L1ERC721Bridge, DataAvailabilityChallenge, SystemConfig, OptimismMintableERC20Factory, OptimismPortal, L2OutputOracle, SuperchainConfig - acting via ProxyAdmin.
    • Can upgrade the implementation of L1StandardBridge - upgrading the bridge implementation can give access to all funds escrowed therein - acting via ProxyAdmin.

    A Challenger.

    • Can change the configuration of DataAvailabilityChallenge - can upgrade the parameters of DA challenges like the bond size or refund percentages, potentially making challenges infeasable or insecure.
    • Can change the configuration of SystemConfig - it can update the preconfer address, the batch submitter (Sequencer) address and the gas configuration of the system.

    A Guardian.

    Smart contracts
    A diagram of the smart contract architecture
    A diagram of the smart contract architecture

    The system consists of the following smart contracts on the host chain (Ethereum):

    Used to bridge ERC-721 tokens from host chain to this chain.

    Can be upgraded by:

    Upgrade delay: No delay

    The DataAvailabilityChallenge contract is used to challenge the full availability of data behind commimted transaction data hashes. See the technology section for more details.

    Can be upgraded by:

    Upgrade delay: No delay

    Contains configuration parameters such as the Sequencer address, gas limit on this chain and the unsafe block signer address.

    Can be upgraded by:

    Upgrade delay: No delay

    ProxyAdmin 0x7617…415F
    • Can be used to configure AddressManager - set and change address mappings.
    • Can be used to upgrade implementation of L1ERC721Bridge, DataAvailabilityChallenge, SystemConfig, OptimismMintableERC20Factory, OptimismPortal, L2OutputOracle, SuperchainConfig.
    • Can be used to upgrade implementation of L1StandardBridge - upgrading the bridge implementation can give access to all funds escrowed therein.

    Sends messages from host chain to this chain, and relays messages back onto host chain. In the event that a message sent from host chain to this chain is rejected for exceeding this chain’s epoch gas limit, it can be resubmitted via this contract’s replay function.

    A helper contract that generates OptimismMintableERC20 contracts on the network it’s deployed to. OptimismMintableERC20 is a standard extension of the base ERC20 token contract designed to allow the L1StandardBridge contracts to mint and burn tokens. This makes it possible to use an OptimismMintablERC20 as this chain’s representation of a token on the host chain, or vice-versa.

    Can be upgraded by:

    Upgrade delay: No delay

    The main entry point to deposit funds from host chain to this chain. It also allows to prove and finalize withdrawals. This contract stores the following tokens: ETH, ATA.

    Can be upgraded by:

    Upgrade delay: No delay

    Contains a list of proposed state roots which Proposers assert to be a result of block execution. Currently only the PROPOSER address can submit new state roots.

    Can be upgraded by:

    Upgrade delay: No delay

    This is NOT the shared SuperchainConfig contract of the OP stack Superchain but rather a local fork. It manages the PAUSED_SLOT, a boolean value indicating whether the local chain is paused, and GUARDIAN_SLOT, the address of the guardian which can pause and unpause the system.

    Can be upgraded by:

    Upgrade delay: No delay

    The main entry point to deposit ERC20 tokens from host chain to this chain. This contract can store any token.

    Can be upgraded by:

    Upgrade delay: No delay

    AddressManager 0xF1C9…04c6

    Legacy contract used to manage a mapping of string names to addresses. Modern OP stack uses a different standard proxy system instead, but this contract is still necessary for backwards compatibility with several older contracts.

    Value Secured is calculated based on these smart contracts and tokens:

    Main entry point for users depositing ERC20 token that do not require custom gateway.

    Can be upgraded by:

    Upgrade delay: No delay

    Main entry point for users depositing ETH, ATA.

    Can be upgraded by:

    Upgrade delay: No delay

    The current deployment carries some associated risks:

    • Funds can be stolen if a contract receives a malicious code upgrade. There is no delay on code upgrades (CRITICAL).
