Facet is a based rollup built on the OP stack. It uses FCT as its native gas token, which is mintable by spending gas on L1.

Value securedTVS

$1.60 M13.4%

Canonically BridgedCanonical

$1.60 M

Externally BridgedExternal

$0.00

Natively MintedNative

$0.00

View TVS Breakdown

Tokens

Daily UOPS

0.000.00%

30D ops count

45.38 K

Stage

Stage 0

Type

Optimistic Rollup

Purpose

Universal

Sequencer failureState validationData availabilityExit windowProposer failure

Badges

About

Facet is a based rollup built on the OP stack. It uses FCT as its native gas token, which is mintable by spending gas on L1.

Facet

Milestones & Incidents

Recategorisation

158d

22h

24m

16s

The project will be classified as "Other" due to its specific risks that set it apart from the standard classifications.

The project will move to Others because:

The proof system isn't fully functional

Consequence: projects without a proper proof system fully rely on single entities to safely update the state. A malicious proposer can finalize an invalid state, which can cause loss of funds.

Learn more about the recategorisation here.

Value Secured

Canonical

External

Native

Onchain costs

Calldata

Blobs

Compute

Overhead

Milestones & Incidents

Facet Mainnet Launch

2024 Dec 10th

Facet launches at Ethereum block 21373000.

Learn more

Risk summary

Sequencer failureState validationData availabilityExit windowProposer failure

Sequencer failure

Self sequence

Users can self sequence transactions by sending them on L1. There is no privileged operator.

State validation

None

Currently the system permits invalid state roots. More details in project overview.

Data availability

Onchain

All of the data needed for proof construction is published on Ethereum L1.

Exit window

None

There is no window for users to exit in case of an unwanted regular upgrade since contracts are instantly upgradable.

Proposer failure

Cannot withdraw

Only the whitelisted proposers can publish state roots on L1, so in the event of failure the withdrawals are frozen.

Rollup stage

Facet is a

Stage 0

Optimistic Rollup.

Learn more about Rollup stages

Please keep in mind that these stages do not reflect rollup security, this is an opinionated assessment of rollup maturity based on subjective criteria, created with a goal of incentivizing projects to push toward better decentralization. Each team may have taken different paths to achieve this goal.

Technology

Fraud proofs are not enabled

OP Stack projects can use the OP fault proof system, already being deployed on some. This project though is not using fault proofs yet and is relying on the honesty of the permissioned Proposer and Challengers to ensure state correctness. The smart contract system permits invalid state roots.

Funds can be stolen if an invalid state root is submitted to the system (CRITICAL).

L2OutputOracle.sol - Etherscan source code, deleteL2Outputs function

All data required for proofs is published onchain

All the data that is used to construct the system state is published onchain in the form of cheap calldata. This ensures that it will always be available when needed.

Operator

There is no central operator

There is no privileged entity that sequences transactions or produces blocks. This activity is permissionless and open to anyone.

Users can force any transaction

Because the state of the system is based on transactions submitted on the underlying host chain and anyone can submit their transactions there it allows the users to circumvent censorship by interacting with the EOA inbox on the host chain directly.

Withdrawals

Withdrawals are initiated on L1

Users can initiate a withdrawal from the L1StandardBridge escrow by sending a transaction to the L1 contract, forcing the operator to either process it, halt all withdrawals or produce an invalid state transition. Deposits from the L1StandardBridge are disabled, and the use of the fast bridge is encouraged. There is no way to force the fast bridge operator (EOA) to process a withdrawal.

Funds can be lost if the fast bridge EOA operator signs an invalid withdrawal (CRITICAL).
Funds can be frozen if the operator halts withdrawals (CRITICAL).

PausedL1StandardBridge.sol - Etherscan source code, disabled _initiateBridgeERC20 function

Other considerations

EVM compatible smart contracts are supported

OP stack chains are pursuing the EVM Equivalence model. No changes to smart contracts are required regardless of the language they are written in, i.e. anything deployed on L1 can be deployed on L2.

Introducing EVM Equivalence

Permissions

The system uses the following set of permissioned addresses:

Guardian (3) FacetSafeModule FacetMultisig EthscriptionsSafeModule

Guardian is an actor allowed to pause deposits and withdrawals.

Challenger EOA 1

Challenger is an actor allowed to challenge or delete state roots proposed by a Proposer.

Proposer EOA 1

Proposer is an actor allowed to post new state roots of the current layer to the host chain.

FacetSafeModule 0x3235…6BCF

Can act on behalf of FacetMultisig.
Can change the configuration of FacetEtherBridgeV6 (acting via FacetMultisig) - can withdraw all funds from the bridge.
Can change the configuration of AddressManager (acting via ProxyAdmin, FacetMultisig) - set and change address mappings.
Can change the configuration of SystemConfig (acting via FacetMultisig) - it can update the preconfer address, the batch submitter (Sequencer) address and the gas configuration of the system.
A Guardian (acting via FacetMultisig).
Can upgrade the implementation of OptimismPortal, SystemConfig, L2OutputOracle, SuperchainConfig (acting via ProxyAdmin, FacetMultisig).
Can upgrade the implementation of L1StandardBridge (acting via ProxyAdmin, FacetMultisig) - upgrading the bridge implementation can give access to all funds escrowed therein.
Module that allows the Safe to send Facet transactions.

FacetMultisig 0xb2B0…C525

A Gnosis Safe with 2 / 3 threshold. It uses the following modules: FacetSafeModule (Module that allows the Safe to send Facet transactions), EthscriptionsSafeModule (Module that allows the Safe to interact with Ethscriptions).
Can act on behalf of ProxyAdmin.
Can change the configuration of FacetEtherBridgeV6 - can withdraw all funds from the bridge.
Can change the configuration of AddressManager (acting via ProxyAdmin) - set and change address mappings.
Can change the configuration of SystemConfig - it can update the preconfer address, the batch submitter (Sequencer) address and the gas configuration of the system.
A Guardian.
Can upgrade the implementation of OptimismPortal, SystemConfig, L2OutputOracle, SuperchainConfig (acting via ProxyAdmin).
Can upgrade the implementation of L1StandardBridge (acting via ProxyAdmin) - upgrading the bridge implementation can give access to all funds escrowed therein.

Participants (3):

0x7761…373C 0xD66C…27a7 0x75de…6127

EthscriptionsSafeModule 0xDB86…22cE

Can act on behalf of FacetMultisig.
Can change the configuration of FacetEtherBridgeV6 (acting via FacetMultisig) - can withdraw all funds from the bridge.
Can change the configuration of AddressManager (acting via ProxyAdmin, FacetMultisig) - set and change address mappings.
Can change the configuration of SystemConfig (acting via FacetMultisig) - it can update the preconfer address, the batch submitter (Sequencer) address and the gas configuration of the system.
A Guardian (acting via FacetMultisig).
Can upgrade the implementation of OptimismPortal, SystemConfig, L2OutputOracle, SuperchainConfig (acting via ProxyAdmin, FacetMultisig).
Can upgrade the implementation of L1StandardBridge (acting via ProxyAdmin, FacetMultisig) - upgrading the bridge implementation can give access to all funds escrowed therein.
Module that allows the Safe to interact with Ethscriptions.

EOA 1 0x034B…7eE3

A Challenger.
A Proposer.

EOA 2 0x314d…1006

Can change the configuration of FacetEtherBridgeV6 - can sign arbitrary withdrawals for users.

Smart contracts

A diagram of the smart contract architecture

The system consists of the following smart contracts on the host chain (Ethereum):

FacetEtherBridgeV6 0x0000…Ce4C Implementation (Upgradable)Admin

Official Facet implementation of the Ether Bridge. This contract stores the following tokens: ETH.

Source code

AddressManager 0x2D96…33aA

Legacy contract used to manage a mapping of string names to addresses. Modern OP stack uses a different standard proxy system instead, but this contract is still necessary for backwards compatibility with several older contracts.

OptimismPortal 0x8649…1eDD Implementation (Upgradable)Admin

The main entry point to deposit funds from host chain to this chain. It also allows to prove and finalize withdrawals. This contract stores the following tokens: ETH.

Can be upgraded by:

FacetSafeModule FacetMultisig EthscriptionsSafeModule

Upgrade delay: No delay

L1StandardBridge 0x8F75…2909 Implementation (Upgradable)Admin

The main entry point to deposit ERC20 tokens from host chain to this chain. This contract can store any token.

Can be upgraded by:

FacetSafeModule FacetMultisig EthscriptionsSafeModule

Upgrade delay: No delay

L1CrossDomainMessenger 0xa123…70E8 Implementation (Upgradable)

Sends messages from host chain to this chain, and relays messages back onto host chain. In the event that a message sent from host chain to this chain is rejected for exceeding this chain’s epoch gas limit, it can be resubmitted via this contract’s replay function.

SystemConfig 0xC1E9…534e Implementation (Upgradable)Admin

Can be upgraded by:

FacetSafeModule FacetMultisig EthscriptionsSafeModule

Upgrade delay: No delay

FacetSafeProxy 0xC9F2…4d25

Helper of the Safe Module that allows to send Facet transactions.

L2OutputOracle 0xD1e4…C5A6 Implementation (Upgradable)Admin

Contains a list of proposed state roots which Proposers assert to be a result of block execution. Currently only the PROPOSER address can submit new state roots.

Can be upgraded by:

FacetSafeModule FacetMultisig EthscriptionsSafeModule

Upgrade delay: No delay

ProxyAdmin 0xe2A3…997C

Can be used to configure AddressManager - set and change address mappings.
Can be used to upgrade implementation of OptimismPortal, SystemConfig, L2OutputOracle, SuperchainConfig.
Can be used to upgrade implementation of L1StandardBridge - upgrading the bridge implementation can give access to all funds escrowed therein.

SuperchainConfig 0xec3a…EA59 Implementation (Upgradable)Admin

This is NOT the shared SuperchainConfig contract of the OP stack Superchain but rather a local fork. It manages the PAUSED_SLOT, a boolean value indicating whether the local chain is paused, and GUARDIAN_SLOT, the address of the guardian which can pause and unpause the system.

Can be upgraded by:

FacetSafeModule FacetMultisig EthscriptionsSafeModule

Upgrade delay: No delay

EthscriptionsSafeProxy 0xeEd4…5095

Helper of the Safe Module that allows to send Ethscriptions transactions.
